Relay

• Low height: 15.7 mm
• 16A switching capability
• 5kV dielectric strength (between coil and contacts)
• Creepage distance: 10mm
• Meeting VDE 0700, 0631 reinforce insulation
• Product in accordance to IEC 60335-1 available
• Plastic sealed and flux proofed types available

•  10A switching capability
•  5kV dielectric strength (between coil and contacts)
•  Sockets available
• Plastic sealed and dust protected types available
• Environmental friendly product (RoHS compliant)
• Outline Dimensions: (29.0 x 13.0 x 26.0) mm

• 20A switching capability
• TV-8 125VAC
• Surge voltage up to 6kV (between coil and contacts)
• Thermal class F: standard type (at 85°C)
• Ambient temperature meets 105°C
• Product in accordance to IEC 60335-1 available
• 1 Form C and 1 Form A configurations available

• Max.switching capability 12A
• 4.0kV dielectric strength (between coil and contacts)
• contact arrangement: 2 Form A
• UL insulation system: Class F
• IEC60335-1 compliant products are available
• 2H products with a single contact gap of ≥0.75mm
• TV-5/TV-8(2H 072) compliant products are available

• Max.continuous current 40A
• 40A switching capability @ 240VAC
• Extended temp. Range up to 85°C
• With highly established reliability
•  High space utilization
• RoHS, ELV compliant

Max.continuous current 32A Extended temp. Range up to 105°C  With highly established reliability Strong resistance ability to shock & vibration Reflow soldering version available RoHS, ELV compliant

• Switching capability up to 20A
• Six different contact arrangements
• Unenclosed and plastic sealed types available
• RoHS & ELV compliant
